IP & NVR System
IP & NVR System
|
IMAGE SENSOR |
1/2.8″ Sony Starvis IMX290 |
|
RESOLUTION |
1080p |
|
MIN. ILLUMINATION |
0.01Lux @(F1.2,AGC ON), 0Lux with IR |
|
IR DISTANCE |
30m |
|
SHUTTER |
Manual /Auto (Adjustable, 1/25~1/100000) |
|
LENS |
Varifocal 2.8mm-12mm, M14 mount |
|
DAY & NIGHT |
Auto (ICR) / Color / Black & White |
|
VIDEO COMPRESSION |
H.265 |
|
VIDEO OUTPUT BITRATE |
128Kbps~8Mbps |
|
AUDIO COMPRESSION |
PCMV/PCMA |
|
AUDIO OUTPUT BITRATE |
64Kbps(G.711) /16Kpbs(G.726) |
|
MAX. RESOLUTION |
Mainstream: 1920 x 1080, Sub-stream: 720×576 |
|
FRAME RATE |
50Hz: 25fps(1920×1080),60Hz: 30fps(1920×1080) |
|
ALARM |
Motion Detection Alarm |
|
PROTOCOLS
|
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PP |
|
INTERFACE PROTOCOL |
ONVIF |
|
GENERAL FUNCTION |
Flicker Filter, Dual-stream, Mirror Image |
|
COMMUNICATION INTERFACE |
RJ45 ( 10M/100M Ethernet) |
|
WORKING TEMPERATURE |
-30°C~50°C |
|
POWER SUPPLY |
DC12V/POE |
|
BRIGHTNESS |
Manual |
|
CONTRAST |
Manual |
|
SATURATION |
Manual |
|
SHARPNESS |
Manual |
|
DAY / NIGHT |
Auto (ICR) / Day / Night |
|
MIRROR |
Open / Close |
|
OTATE IMAGE |
Open / Close |
|
WIDE DYNAMIC RANGE |
Enable / Disable (Value 1 – 10) |
|
MOTION DETECTION |
Yes |
|
VIDEO MASKING |
Yes |
|
IMAGE SOURCE |
50Hz / 60Hz |
