Model

SF-D9116T-H

System

Processor

HI3531

Video

Picture Coding

H.264(High Profile)

Encode Capacity

16*AHD-M

Decode Capacity

4*AHD-M

Multi-mode Input

Pure Analog: 16*AHD-M; 8*AHD-M; 16*AHD-L;

Mixed: 4*AHD-M(Analog)+4*720P(Network);

Pure Network: 1*1080P+8*720P; 4*1080P; 20*960P

Audio

Audio Compression

G.711A

Intercom

Support

Record & Playback

Record Mode

Manual>alarm>motion detection>timing

Playback Channels

4-ch(pure local input mode)

Storage & Backup

Space Occupation

960H:12~20G/ day*channel; 720P:20G~30G/ day*channel;

Audio:691.2M/ day*channel

Backup Mode

Network backup, USB HDD, USB writer, SATA writer

Interface

Video Input

16-ch BNC

video Output

1-ch VGA, 1-ch HDMI

Audio Input

2-ch RCA

Audio Output

1-ch RCA

Alarm Input

No

Alarm Output

No

Net Interface

1 RJ4510M/100Madaptive Ethernet Interface

Control Interface

1 RS485, support multiple PTZ protocols

USB Interface

2 USB Interfaces

Hard Disk Interface

1 SATA Interface (Max 4TB)

Wireless Interface

WIFI/3G

General

Power Supply

12V/2A

Dimension

255mm*225mm*45mm
