pecification

2MP bkacklight 38 module

System

Embedded RTOS design, 32 bits DSP(Hi3516EV200),pure hardware compression,watchdog,64MB built in DDR,8M flash;

Structure

Sensor

SONY STARVIS 2MP 1/2.8"(IMX307LQR),,0.001Lux@F1.2(color),0Lux(IR ON);integrate IR-CUT drive, support linkage control between sensor &IR-CUT& photosensitive& LED fill light, support day/night switch,IR-CUT and lens mount optional;

Video Process

H.265+/H.265/H.264 video coding, support dual stream, AVI format; code stream 200~8000kbps adjustable; support PAL and NTSC

Frame Rates

2MP @30FPS,support 7~30 FPS adjustable

Image Output

Main stream:1920×1080,1280×960,1280×720;

Sub stream:800×448,640×480,640×360,352×288;

Audio interface

1channel input,support mic or pickup input;1channel output, support headset or amplifier play

Audio Process

G.711 CODEC standard, support dual voice talkback, audio and video synchronization;

Network Interface

1*RJ45 Ethernet interface,10/100M self-adaption,8KV anti-static electric capacity;support RTSP/DHCP/NTP, GB/T28181,compatible ONVIF and so on network protocols;

LED Passive Interface

1* IR LED control output interface,1*IRCUT interface, support linkage control between IR-CUT and image.

Mine-protected

Power supply, network comprehensive lightning protection, through the ITU-T, K.21-2008, IEC61000-4-2/IEC61000-4-5 and other lightning protection standards testing

Business Functions

Configure by WEB, OSD(on screen display),real-time video transmission, motion detection and IO alarm linkage ,center prompt and picture pop-up after IO alarm; support remote surveillance client software(Seetong);support mobile monitoring(Iphone, Android),support "Seetong" cloud service;

Power Supply

DC12V power input interface,1308mW power consumption, front end power input, light protection,anti-static,anti-inverse connect, support 18V turn off voltage protection;

Size and weight

size :38×38×11mm, net weight 8g, without housing PCBA,38 size single structure;

Work Conditions

-20℃～+ 45℃

Optional Functions

E(POE cable power supply).
