Camera Model

AS-MHD2203H5

Image Sensor

Sony IMX335

DSP

NVP2477

Image Resolution

5MP

Effective Pixels

2592(H) x 1944(V)

TV System

PAL/NTSC

Electronic Shutter

1/25s~1/50,000s , 1/30s~1/60,000s

S/N Ratio

≥50dB

Scanning System

Progressive Scan

Lens

Focus Length

3.6mm

Focus Control

Fixed

Lens Type

Fixed

Pixels

5M Pixels

Auto Iris Support

NO

Night Vision

Infrared LED

24PCS IR-Led

Infrared Distance

20M

IR Status

Under 10 Lux by CDS

IR Power On

Auto Control

Camera Features

Day/Night

YES

OSD Menu Language

YES

White Balance

AUTO / MANUAL

Gain Control

AUTO

Noise Reduction

3DNR

Picture Adjustment

YES

WDR

YES

OSD  Support

YES

General

Housing

Metal

Bracket

NO

Dual Voltage

NO

IR Cut Filter

YES

Heater

NO

Operation Temperature

-10℃ ~ +50℃ RH95% Max

Storage Temperature

-20℃ ~ +60℃ RH95% Max

Power Source

DC12V±10%, 300mA
