Camera
Product Name AHD 360 Degree Outdoor IR Fish Eye Camera
Model No.
Imaging Sensor 1/3" CMOS, 1.3 Megapixel, AHD output
Lens 360 degree fisheye lens
Video
Compression H.264
Pixels 1080 H x 960
Scanning 2:1 Interlace
Sync Mode Internal
Horizontal and Vertical Frequency PAL:15.625 kHz, 50.00 HZ /  NTSC :15.734kHZ,59.94HZ
Video Output 1.0Vp-p/75Ω Composite video signal
S/N Ratio >60dB  AGC Off
AGC Auto
E-shutter PAL:1/50-1/100,000 s / NTSC:1/60-1/100,000s
Illumination 0.005lux
Power 12VDC(±10%)
Consumption 1W(Max)
Operating Temperature and humidity -10c-50c,20%-90% RH
Dimension 118*99mm
